Resin matrix composite is a kind of composite material prepared by specific molding process with resin as matrix and fiber as reinforcement. According to the matrix, it can be divided into thermoplastic composites and thermosetting composites. The composition of thermoplastic composites is as follows:
Some abbreviations often appear in thermoplastic composite materials. This paper introduces the following:
1. CFRTP: abbreviation of continuous fiber reinforced thermoplastic composites, continuous fiber reinforced thermoplastic composites. As the name suggests, the reinforcing material of this material is continuous fiber, which corresponds to long fiber reinforced thermoplastic composite (LFT) and short fiber reinforced thermoplastic composite (SFT).
2. GMT: abbreviation of glass mat reinforced thermoplastic, glass mat reinforced thermoplastic composite. Generally, the fiber content of GMT is between 30wt% and 40wt%, which is higher than that of ordinary injection molding reinforced plastics. Moreover, it uses a continuous glass fiber needled felt, which is continuously paved into a felt and given a certain strength by needling. It has a three-dimensional structure, and there are fibers in all directions, which greatly improves the anisotropy of reinforced plastics. It is widely used in various fields.
3. RTP: it is the abbreviation of continuous fiber reinforcedthermoplastic composites, which is reinforced thermoplastic pipes. RTP pipe is an important application field of CFRTP coil at present. The application of domestic RTP pipe is still in its infancy, but it has great potential.
4. LFT: it is the abbreviation of long fiberreinforced thermoplastics. There are two kinds of long fiber reinforced thermoplastic composites: lft-g (granules) and lft-d (direct). Compared with ordinary fiber-reinforced thermoplastic materials, generally, the fiber length in fiber-reinforced thermoplastic materials is less than 1 mm, while in LFT, the fiber length is generally more than 2 mm. With the gradual maturity of the molding process, the fiber length in LFT can be maintained at more than 5 mm. The resin is impregnated with long fibers through the mold to get a long strip fully soaked by the resin, and then cut into the required length as required.
5. SMC: it is the abbreviation of sheet moldingcompound. Sheet molding compound is a kind of FRP. The main raw materials are GF (special yarn), MD (filler) and various additives. The commonly used resin is unsaturated polyester resin. SMC has high mechanical strength, flame retardancy, arc resistance, dielectric strength and voltage resistance, and this material is easy to color. It is usually used for various insulating partitions in electric cabinets.
6. BMC: it is the abbreviation of bulk moldingcompound. The bulk molding compound is a kind of paste made of unsaturated polyester resin, low shrinkage / low profile additives, initiators, internal release agents, mineral fillers, etc. and then added with thickeners, colorants, etc. with glass fibers of different lengths, it is stirred in a special kettle for thickening process, and finally forms a bulk intermediate material, which can be used for molding and injection molding. BMC has more minerals than SMC, and its electrical properties and chemical corrosion resistance are good. The application in motor shell has obvious advantages.
Recently, Beijing XX company held a press conference and officially announced its five new energy-saving and emission reduction products, including three oil field specific products: downhole energy-saving and production increasing technology - Super vibration plugging removal device, intelligent air pumping controller of pumping unit, and super wear-resistant packing device of pumping unit; There are also two products that attract the most attention: a full set of "marine fuel oil turbulence + phacoemulsification" devices that introduce the core technology of the United States, and the world's most advanced "severon brand engine quick acting repair agent" that is originally produced in Germany. The launch of these two products indicates that Beijing XX company will try its best to seize the energy-saving and emission reduction market in the domestic large-scale automotive and marine industry.
Perhaps, for many people, XX company is a relatively strange enterprise, but in the industry, XX company is famous. At the beginning of its establishment in 1998, XX company was specialized in high-end products in the field of oil exploration and development, and occupied a prominent position in the industry. In 2002, the company began to pay attention to the research and development of energy-saving and emission reduction technologies in the energy field. However, what makes the insiders confused is that in these years, XX company has not launched new and world-class products, but devoted itself to research, so that many insiders believe that XX company has become a scientific research institution.
Today, with the launch of five new products, Beijing XX company once again appears in the field of vision of the industry. As the saying goes, the "turbulence of marine fuel oil + phacoemulsification device" and "quick acting engine repair agent" launched by XX this time represent the highest level of similar products in the world, and are at the world's leading level in terms of technology and application effect. Some experts believe that the launch of these two products will become a watershed in the development trend of domestic peer products, and can even be called the phased benchmark of industry development.
According to the relevant person in charge of Beijing XX company, after repeated research and analysis of the market, it is believed that energy conservation and emission reduction will be the focus of China's development in the future, and energy-saving and emission reduction products in the field of energy will become an important field in the market. Over the years, the research and development in the oil field has also accumulated very rich experience for XX, especially for the unique vision related to energy products. In the next few years, XX will vigorously promote the application of these technologies and do its part for China's energy conservation and emission reduction.
